A Technical Introduction to the Asterisk Gateway Interface (AGI)

Gate Sketch

The Asterisk Gateway Interface, commonly referred to as AGI, is a language-independent API for processing calls. It allows programmers to write simple programs to manipulate and route calls on Asterisk servers in a simple, easy manner.

This article provides a technical introduction to the AGI, explaining how it works, how it can be used, where you can find API documentation, and even provides some basic code samples which demonstrate how to use the AGI. The intended audience is programmers, telephony enthusiasts, or IT people who want to learn more about adding functionality to their Asterisk PBX systems. This is not a full programming reference, and will not explain how to write AGI programs, it will merely teach you what the AGI provides and how to use it high-level.

Why Use AGI?

One question that arises frequently is Why do I need to use the AGI? This is a great question, worth discussing. Asterisk provides several ways to perform call logic, namely dial plan, AMI, and AGI.

Dial plan is Asterisk’s native scripting language which is parsed by Asterisk and stored in memory to use for performing call logic. Dial plan is quick, efficient, and easy to learn. There are, however, downsides associated with dial plan. It is very unsophisticated, and doesn’t support standard procedural language constructs (like loops). This means that you will be doing mostly assembly type coding using Goto statements and simple constructs. This makes writing large software tedious and difficult to maintain.

The Asterisk Manager Interface (AMI) is a sophisticated, language independent API for controlling Asterisk through TCP sockets. The AMI is a great solution for software that needs to be ran on remote servers as it can interact with Asterisk across networks. Many click-to-call programs are written using the AMI, as are nearly all of the Asterisk manager programs like HUD, FOP, and Asterisk Assistant. The AMI is great because it allows remote software to completely control the Asterisk PBX: get even status updates, make calls, receive calls, route calls, etc. The downside to using the AMI is that it does not have any good documentation, is known to be buggy and error-prone, and causes significant stress on the PBX.

The AGI is a middle man, lying somewhere between dial plan and the AMI in terms of functionality. The AGI can not be completely independent of the PBX, and requires some dial plan modification to run (unlike the AMI), is not bound to a specific programming language (like the AMI), and can be used either locally or across networks (like the AMI). The AGI is usable only for incoming calls, and is thus no good for purely outbound telephony development. The AGI uses little overhead compared to the AMI, and is a good solution for developers who want to write a module or plugin for Asterisk which can be used on any PBX and implemented quickly and simply without stressing the server. AGI is also a great solution for developers who would like to create telephony programs without learning the Asterisk dial plan. It lets you build applications in whatever programming language you are comfortable with, which can rapidly decrease development time.

The Four Types of AGI

The AGI actually has four ways in which it can be used, each different from the other. There is the standard AGI, dead AGI, fast AGI, and enhanced AGI.

Standard AGI is the simplest, and most widely used form of AGI. Standard AGI scripts run on the local PBX and communicate with Asterisk through socket descriptors (namely STDIN and STDOUT). The standard AGI allows for usage of all AGI commands, and is what this article will be discussing.

The dead AGI is a simplified form of AGI which continues to run after the call has been hung up. This is useful in situations where programming logic needs to be performed after a call has hung up. As dead AGI allows developers to control logic after the call, certain AGI commands are not permitted in its usage. Dead AGI is also deprecated as of Asterisk 1.6, and should not be used.

Fast AGI is the AGI over TCP sockets protocol. It allows for all AGI functionality except EAGI, and is provided as a solution to developers who need to run resource intensive AGI programs. By running the bulk of the AGI logic on another server, the Asterisk server itself can process calls and not worry about handling complex computation for other services. This is the recommended protocol for large applications.

Last is the EAGI. The EAGI communications through file descriptors on the local machine using STDIN and STDOUT, and provides developers a way to access the audio channel directly for the calls being processed. This is rarely used, but gives developers a way to analyze raw audio data.

How to Run an AGI Program

When calls come into the Asterisk server, the dial plan rules process the call and determine where to route it. To launch an AGI program and hand off call processing the AGI program, you will need to use the Asterisk dial plan command AGI. Below is an extremely simple example dial plan which passes all calls to an AGI script for processing.

; This dial plan code passes all call processing to the call-processor.sh shell
; script.

[incoming]
exten => _X.,1,AGI(call-processor.sh)

By default, if no path is specified, Asterisk will look for the script, in this case call-processor.sh, in the directory /var/lib/asterisk/agi-bin. This is the default location for all AGI programs, and should probably be used to store your AGI software. If your program resides in another directory, you may specify an absolute path to the program for Asterisk to use instead.

The program must be executable (on Linux systems that means that the executable bit must be set on your program). You can do this by using the Linux command chmod +x to add the executable bit to your program.

The program must also be readable by Asterisk, this means that it must be in a public directory tree, or a tree that is owned by the user account under which Asterisk runs. Also, don’t forget that your AGI program will be ran by Asterisk, so permissions are necessary to plan out in advance. A common problem new Asterisk developers run into is that they will have their AGI programs write files to a system location, like /etc/, but Asterisk will be running in a restricted environment, so their programs will fail and they will not know why.

Testing AGI Scripts (live)

Running AGI scripts, as explained in the previous section is a simple task. Sometimes, however, debugging AGI scripts can be difficult and time consuming. Often, it is difficult to test AGI programs as you cannot simply print output to the screen as you normally would for debugging purposes. This section briefly covers using the Asterisk command line to watch and debug AGI applications live.

To get started, log into the asterisk console via the asterisk -r command from the shell. Once inside the CLI, run the agi set debug on command to enable verbose AGI output. This will come in handy when troubleshooting your programs. Below is an AGI debug of an AGI application which shows a wide array of information about my AGI application. Take a close look at this debug, and try to make sense of it. I’ll explain what each bit means below.

AGI Tx >> agi_request: hello-world.sh
AGI Tx >> agi_channel: SIP/flowroute-ac10d3c8
AGI Tx >> agi_language: en
AGI Tx >> agi_type: SIP
AGI Tx >> agi_uniqueid: 1266365654.10672
AGI Tx >> agi_version: 1.6.1.1
AGI Tx >> agi_callerid:
AGI Tx >> agi_calleridname: unknown
AGI Tx >> agi_callingpres: 0
AGI Tx >> agi_callingani2: 0
AGI Tx >> agi_callington: 0
AGI Tx >> agi_callingtns: 0
AGI Tx >> agi_dnid:
AGI Tx >> agi_rdnis: unknown
AGI Tx >> agi_context: inbound
AGI Tx >> agi_extension:
AGI Tx >> agi_priority: 1
AGI Tx >> agi_enhanced: 0.0
AGI Tx >> agi_accountcode:
AGI Tx >> agi_threadid: 1097206080
AGI Tx >>
AGI Rx << ANSWER
AGI Tx >> 200 result=0
AGI Rx << NOOP hello, world!
AGI Tx >> 200 result=0
AGI Rx << HANGUP
AGI Tx >> 200 result=1

Now, the first thing to note is that every line starts with the channel ID of the call, this way, calls can be traced even on very busy servers. If you have a lot of call traffic, filtering out lines by their channel ID can help improve visibility. A great way to do this is to use grep, ex: asterisk -r | grep from the command line.

AGI applications send commands to Asterisk via STDOUT, and Asterisk sends data to your AGI programs via STDIN.

After the channel ID, you’ll see AGI followed by either Tx or Rx. Tx stands for transmit, and means that Asterisk is transmitting the following information into the STDIN buffer for your AGI program to use if it desires. Lines which begin with Rx (receive) display information that your AGI program is sending to Asterisk into the STDOUT buffer. If you ever find yourself wondering what response you are getting after sending a command to Asterisk via AGI, you can always look at the Tx lines to see what Asterisk says.

The first 21 lines of output are all transmissions from Asterisk, which are sent into the STDIN buffer for your program to use if it wishes. Each of these lines defines a call variable which contains information about the call that is currently being processed. This information may be used by your programs to figure out things like what caller ID the person calling is using, what number they called, what dial plan context were they in before hitting your AGI application, what language the call is in, what version of Asterisk is being used, etc.

Note that this initial list of variables is terminated by a single empty line. So when writing software to parse in these variables, always keep parsing until you read in an empty line. That is how you can tell that there is no further input.

The next few lines are dialog between our AGI application and Asterisk. The Rx lines show AGI commands which were sent to Asterisk for processing, and the following Tx lines show Asterisk responses.

AGI Hello World Application

In the previous section, we looked at an AGI call log. Now let’s examine the AGI application which ran and generated that call log. What follows is an extremely simple AGI application which simply outputs hello, world! to the AGI debug output.

#!/bin/bash

echo "ANSWER"
echo "NOOP hello, world!"
echo "HANGUP"

This program completely disregards all of the variables that Asterisk passed into STDIN when it spawned a new thread for our AGI application, and only writes three AGI commands to STDOUT (which is how our application communicates with Asterisk).

The first command we send is ANSWER, which does nothing but answer the call (establishes an audio connection with the remote end, so that the call starts getting billed). The second command we send is a NOOP, which only outputs the text that follows it onto the AGI debug screen of the CLI. Lastly, we send the HANGUP command which ends the call.

Simple enough? Now, go ahead and try to run this program yourself. Test it out, understand what is happening, and make it work.

One thing you may notice is that you may get some errors on the CLI while watching your program run. Usually they look something like this:

[Feb 16 19:14:15] ERROR[25770]: utils.c:1126 ast_carefulwrite: write() returned error: Broken pipe
[Feb 16 19:14:15] ERROR[25770]: utils.c:1126 ast_carefulwrite: write() returned error: Broken pipe

Feel free to ignore those errors. Those are generated when your AGI application does not read in all data from STDIN before your program closes.

In most real world applications, you’ll want to read in Asterisk responses so that you know whether or not your commands executed successfully, and can grab important information about the call being processed, but for this example, we don’t care, so we didn’t.

Passing Arguments to Your AGI Application

Now that you know how to write and use basic AGI scripts, let’s get a little more advanced. Many complex AGI applications may need more advanced data given to them than what Asterisk natively provides. Luckily, the Asterisk dial plan command AGI allows for us to pass up to 127 arguments to our AGI application. This should be sufficient for most needs.

To pass arguments from the dial plan to your AGI script, you can simply add them in a comma delimited list after your AGI application path is specified:

exten => s,1,AGI(hello-world.sh,arg1,arg2,arg3)

As you’ll notice in the above example, I did not put spaces after each comma. That is because if you add spaces, Asterisk will interpret them literally and your program will receive the argument with a space character prepended to it. This may (or may not) be desirable, based on your application specifications.

The arguments will be available to your AGI application both via the standard argument list and via the initial Asterisk variable list. Each programming language handles it differently. Here is an AGI log which shows our old hello-world.sh program being called with 3 arguments:

AGI Tx >> agi_request: hello-world.sh
AGI Tx >> agi_channel: SIP/flowroute-ac10d3c8
AGI Tx >> agi_language: en
AGI Tx >> agi_type: SIP
AGI Tx >> agi_uniqueid: 1266365654.10672
AGI Tx >> agi_version: 1.6.1.1
AGI Tx >> agi_callerid:
AGI Tx >> agi_calleridname: unknown
AGI Tx >> agi_callingpres: 0
AGI Tx >> agi_callingani2: 0
AGI Tx >> agi_callington: 0
AGI Tx >> agi_callingtns: 0
AGI Tx >> agi_dnid:
AGI Tx >> agi_rdnis: unknown
AGI Tx >> agi_context: inbound
AGI Tx >> agi_extension:
AGI Tx >> agi_priority: 1
AGI Tx >> agi_enhanced: 0.0
AGI Tx >> agi_accountcode:
AGI Tx >> agi_threadid: 1097206080
AGI Tx >> agi_arg_1: arg1
AGI Tx >> agi_arg_2: arg2
AGI Tx >> agi_arg_3: arg3
AGI Tx >>
AGI Rx << ANSWER
AGI Tx >> 200 result=0
AGI Rx << NOOP hello, world!
AGI Tx >> 200 result=0
AGI Rx << HANGUP
AGI Tx >> 200 result=1

As you can see, after the initial arguments have been passed, Asterisk simply adds a new line with for each additional argument passed to the AGI script. This makes reading in these variables easy and doesn’t require any extra effort on your part.

Where to Get AGI Information

Now that we’ve introduced and explained how AGI programs work, there is nothing left to do except start writing some for yourself! The definitive reference to AGI commands and functions can be found on VoIP Info’s AGI page.

If you are comfortable with Asterisk dial plan, you’ll easily pick up the AGI commands. If you have no prior experience, then look for some references / examples in the VoIP info page as they have numerous examples and help available.
